Smart Grid
Technical information for SGIM by BeEnergy SG
General
| Supply voltage: | 100 VACmin .. 240VACmax / 47Hz .. 63Hz |
| Power consumption: | max. 25VA |
| Operation Temperature: | -5°C .. +55°C nominal -20°C .. +70°C derating |
| Relative humidity: | 0% .. 90% no condensation |
Protection
| Insulation protection: | EN 61010-1 |
| Environmental protection: | IP 21 |
Communication
| RS 232: | 300 .. 115200 Baud | |
| RS 485: | 300 .. 115200 Baud | |
| Ethernet | electrical: fibre-optical: |
10/100BaseT 100BaseLX10 SC Duplex single-mode |
| Bluetooth | 4.0 | |
| Radio | UMTS: LTE: LoRaWAN: |
Mini SIM – SMA Antenna Mini SIM – SMA Antenna 868MHz – RF 2-10km – Class A 1.0.1 |
